Laser Diode & Array Driving
A laser diode is a current-driven device, not a voltage-driven one. Its optical output tracks the current through the junction, and that junction has almost no tolerance for the kinds of transients a careless supply produces. Drive it from a stiff voltage source and a small change in forward voltage becomes a large, uncontrolled swing in current, which shows up as an unstable optical pulse at best and a damaged emitter at worst. The job of a diode driver is to deliver a defined current with a defined edge, hold it flat for the pulse, and then return cleanly to zero, all while keeping the device safe through power-up, power-down, and fault conditions.
Berkeley Nucleonics, through its Directed Energy Division, builds current-source drivers for exactly this work. The same design discipline scales from a 3 A precision source feeding a single emitter to a 200 A module driving a stacked array, so a lab can standardize on one architecture across a range of optical loads.
The challenge
Three problems sit at the center of diode and array driving. The first is current control. The pulse the emitter sees has to match the pulse the experiment asked for, in amplitude, in width, and in edge speed, without overshoot that pushes the junction past its rated current. The second is compliance voltage. A current source can only force its programmed current if it has enough voltage headroom to overcome the forward drop of the diode string plus the resistive and inductive drops in the cabling. Stack more bars in series and the required compliance climbs, so the driver has to carry margin or the pulse flattens and distorts.
The third problem is protection. A diode array represents a large investment, and a single fault can take it out in microseconds. The driver has to guard against reverse voltage, has to limit current under a short, and has to leave the output in a safe state whenever it is disabled rather than floating in a way that could stress the load. Cabling matters here too. Series inductance in the path between driver and diode slows the edge and rings the pulse, so the physical connection is part of the circuit, not an afterthought.
The BNC approach
DEI drivers are built as true current sources with the output stage and protection treated as one system. The user programs current, and the driver holds that current across the pulse as long as it stays inside its compliance window, which is published per model so a system designer can budget headroom against the diode string before ordering. This matters most for QCW operation, where the device runs quasi-continuous-wave bursts that sit between short pulsed shots and full CW drive. QCW lets an array reach high average optical power without the continuous thermal load of true CW, and it depends on a driver that can hold a long, flat current pulse rather than just a fast spike.
Output protection is designed in rather than bolted on. The drivers are built so that a disabled output is a safe output, with the load shorted on disable rather than left to ring or reverse. Over-current limiting and reverse-voltage guarding protect the array through fault events and through the moments of power-up and power-down when many systems are most vulnerable. To keep the delivered edge clean, BNC recommends low-inductance cabling kept as short and as tightly paired as the layout allows, because the driver can only present a fast edge to the diode if the path between them does not swallow it.
The lineup spans the practical range of optical loads. For a single emitter or a small bar where precision matters more than raw current, the PCX-7401 delivers up to 3 A with 15 V of compliance and roughly 100 ns rise, across a 5 Hz to 1 MHz range. Where a bench needs more current with both CW and QCW capability, the PCX-7421 supplies 21.5 A with 24 V compliance and edges under 25 ns. For OEM integration into a larger instrument, the PCO-6131 and PCO-6141 modules deliver 125 A and 60 A respectively with variable rise-time control, and the high-current end is served by the PCM-7700 at 200 A and the compact PIM-Mini-200, also at up to 200 A in a small package. These figures are model capabilities; confirm the exact amplitude, compliance, and edge for your configuration against the current published datasheet.
Recommended instruments
Match the driver to the load. Start from the diode string: count the series voltage drop, add cabling drops, and pick a driver whose compliance carries margin above that total at your target current.
- PCX-7421: 21.5 A CW/QCW, 24 V compliance, sub-25 ns rise. A strong default for bars and small arrays that need both CW and QCW modes.
- PCX-7401: 3 A precision source, 15 V compliance, for single emitters and low-current work where pulse fidelity is the priority.
- PCO-6131: 125 A OEM module with variable rise-time control, for integration into a larger optical instrument.
- PCO-6141: 60 A OEM module with variable rise-time control, a lighter-current companion to the PCO-6131.
- PCM-7700: 200 A driver for high-current arrays and long, flat QCW pulses.
- PIM-Mini-200: up to 200 A in a compact form factor for space-constrained benches and embedded systems.
Getting started
Define the load first: peak current, pulse width, repetition rate, and whether the work is single-shot, pulsed, QCW, or CW. Sum the forward voltage of the series string and add headroom for cabling so you can size compliance correctly. Plan the physical connection for low inductance, keeping the run short and the conductors tightly paired, then confirm the protection behavior you need on disable and under fault. Talk to a BNC applications engineer at info@berkeleynucleonics.com or 800-234-7858, and an engineer will help match a driver to your array.
